FG Technology EOBD2 Slave Tool

FG Technology EOBD2 Slave Tool

€2,650.00

The FG Technology EOBD2 Slave Tool is a versatile vehicle communication interface (VCI) used for reading and writing engine and transmission control unit data. Engineered for simplicity and security, the Slave version allows technicians to extract encrypted ECU files and send them to a designated Master for professional modification. It supports a comprehensive range of protocols, including OBD, Bench, Boot Mode, and BDM/JTAG, all within a single device. Compatible with 12V and 24V systems, it is the ideal “plug-and-play” solution for garages looking to provide safe, expert-backed tuning for cars, trucks, motorcycles, and marine engines.

SKU: Categories: Chip TuningTags: 24V ECU Tool, BDM JTAG Tool, Bench Mode Programming, Checksum Correction, ECU Programmer, EOBD2 Slave, FG Technology, FGTech Galletto, Infineon Tricore Boot, Marine Engine Tuning., OBD2 Tuning, Professional Tuning Network, Slave Remapping Tool, TCU Tuning, Tractor Chiptuning, Truck Tuning

Streamlined Tuning for Modern Workshops

The EOBD2 Slave Tool (often associated with the FGTech Galletto lineage) is built on a “Network Model” of business. By using a Slave tool, you benefit from the safety of proven, dyno-tested files provided by your Master, while avoiding the massive investment in file-editing software (like WinOLS) and the technical liability of writing your own maps.



Key Technical Pillars & Semantic Entities:

  • All-In-One Communication: Unlike many tools that require separate hardware for OBD and Bench work, the EOBD2 interface handles OBDII, JTAG, BDM, and Tricore Boot modes using a single main unit.



  • Encrypted File Transfer: The tool automatically encrypts every file it reads from a vehicle. These files can only be decrypted and modified by your specific linked Master, ensuring a secure and exclusive business relationship.



  • Universal Voltage Support: Natively supports 12V and 24V power, making it a rugged choice for heavy-duty tractor and truck tuning where high-amperage stability is required.



  • Bench +ULTRA Extension: Supports the latest “Bench” protocols which allow you to read/write the ECU via the pinout without opening the casing, preserving the factory seal and reducing the risk of physical board damage.

  • Automatic Checksum: Includes built-in checksum correction for most protocols, ensuring the vehicle’s software remains valid and the engine starts immediately after flashing.



Technical Compatibility:

Category Supported Protocols / Systems
Connection Types OBDII, BDM (Motorola MPC), JTAG (Renesas), Boot Mode (Infineon Tricore)
Vehicle Types Cars, Motorcycles, Trucks, Agricultural Tractors, Marine Vessels
Voltage 5V – 30V Auto-Switching
Software EOBD2 Proprietary Suite (Available in 17+ languages)

Business Advantage: The Slave tool is significantly more affordable than the Master version. If your business grows to the point where you wish to write your own files, FG Technology offers an upgrade path to convert your Slave hardware into a Master tool (subject to release by your current Master).
